Completions
NEI-IX-HP
NEI-IX-HP hydraulic set, double grip, retrievable packer with compact construction,
making it particularly suitable for deviated wells and multi packer completions.
SIZES: 4 1/2 – 13 3/8
PRESSURE RATING: 10,000 PSI
ELASTOMERS: NBR/HNBR/VITON/AFLAS
TEMPERATAURE RATING: 325 DEG F
CONNECTION: EUE OR GAS TIGHT CONNECTION
MATERIAL: CARBON STEEL OR CHROME METTALURGY
SETTING MECHANISM: HYDRAULIC
RELEASE MEACHANISM: STRAIGH PULL
ACCESSORIES: PUMP OUT PLUGS / CERAMIC DISC
NEI-XII-ESP
NEI-XII-ESP Packer is hydraulic-set, double-grip retrievable production packer used as a low-pressure packer in a submersible pump completion.
SIZES: 5 1/2 – 9 5/8
PRESSURE RATING: 5,000 PSI
ELASTOMERS: NBR/HNBR/VITON/AFLAS
OF CONTROL LINES: 1/4 X 3 (*CUSTOMIZED AS PER REQUIREMENTS)
OF PENTRATOR BORE: 1
TEMPERATAURE RATING: 325 DEG F
CONNECTION: EUE OR GAS TIGHT CONNECTION
MATERIAL: CARBON STEEL OR CHROME METTALURGY
SETTING MECHANISM: HYDRAULIC
RELEASE MEACHANISM: STRAIGH PULL
ACCESSORIES: NEI – PACKER PENETRATORS / NEI – ADJUSTABLE UNION
NEI-IX-MP
NEI-IX-MP is a Mechanical retrievable production packer that is set mechanically.
The J-design that the Packer is equipped with, allows the packer to continue performing in Tension, Compression and Neutral conditions, without the need to keep the tubing under compression.
The Packer features and internal bypass and Releasing slip system that facilitates release and retrieval of the packer
SIZES: 4 1/2 – 9 5/8
PRESSURE RATING: 10,000 PSI
ELASTOMERS: NBR/HNBR/VITON/AFLAS
TEMPERATAURE RATING: 325 DEG F
CONNECTION: EUE OR GAS TIGHT CONNECTION
SETTING MECHANISM: *RIGHT/LEFT HAND SET
MATERIAL: CARBON STEEL OR CHROME METTALURGY
NEI-R3D-PACKER
NEI-R3D-PACKER Mechanical set single/double grip retrievable packer holds pressure from above and below.
The Packer is set by application of quarter turn rotation, followed by slacking off weight onto the packer.
Simple quarter turn setting mechanism, allows for multiple setting and unsettling cycles in a single run, thereby making it ideal for testing of the casings, stimulation and treating applications in a double-grip configuration
TYPE: SINGLE/DOUBLE GRIP
SIZES: 4 1/2 – 9 5/8
PRESSURE RATING: 10,000 PSI
ELASTOMERS: NBR/HNBR/VITON/AFLAS
TEMPERATAURE RATING: 325 DEG F
CONNECTION: EUE OR GAS TIGHT CONNECTION
SETTING MECHANISM: *RIGHT/LEFT HAND SET
MATERIAL: CARBON STEEL OR CHROME METTALURGY
NEI-RTTN
NEI-RTTN Packer is a compression set packer with hydraulic hold down that is provide additional dependability even in rough service conditions. The Hydraulically actuated upper dies, ensure that the packer does not move up during operation.
It is ideally suited for any acid stimulation, cement squeeze job which can be run in tandem with a Retrievable Bridge Plug for isolating and treating each interval separately.
Available Axial and Rotational Setting Mechanism.
SIZES: 4 1/2 – 13 3/8
PRESSURE RATING: 10,000 PSI
ELASTOMERS: NBR/HNBR/VITON/AFLAS
TEMPERATAURE RATING: 325 DEG F
CONNECTION: EUE OR GAS TIGHT CONNECTION
MATERIAL: CARBON STEEL OR CHROME METTALURGY
ACCESSORIES: STORM VALVE, SAFETY JOINT, UNLOADER VALVE
NEI –NEI-SCSSSV-T
SURFACE CONTROLLED SUBSURFACE SAFETY VALVES
TYPE: SELF-EQUALIZING OR NON-EQUALIZING
SIZES: 2 3/8, 2 7/8, 3 1/2
PRESSURE RATING: 10,000 PSI
TEMPERATAURE RATING: 325 DEG F
CONNECTION: EUE OR GAS TIGHT CONNECTION
MATERIAL: CARBON STEEL OR CHROME METTALURGY
NEI – CONTROL LINES
TYPE: SEAMLESS/WELDED
NEI – CONTROL PANEL
NEI-Landing Nipples
NEI-Landing Nipples are run into the well on the completion tubing to provide a specific landing location for respective lock mandrels.
The profiles of landing nipples and lock mandrels are universal.
PROFILE: OTIS (X, XN, R, RN)/BAKER TYPE (F/R)
SIZES: 2 3/8, 2 7/8, 3 1/2, 4 1/2
PRESSURE RATING: 10,000 PSI
TEMPERATAURE RATING: 325 DEG F
CONNECTION: EUE OR GAS TIGHT CONNECTION
MATERIAL: CARBON STEEL OR CHROME METTALURGY
NEI-SSD
NEI-SSD, sliding sleeve run on the production tubing, mechanically shifted using standard slickline methods.
Intended to control the flow between the tubing and casing.
TYPE: SHIFT DOWN TO OPEN / UP TO OPEN
PROFILE: OTIS (X, XN, R, RN)/BAKER TYPE (F/R)
SIZES: 2 3/8, 2 7/8, 3 1/2, 4 1/2
PRESSURE RATING: 10,000 PSI
SEALS: ELASTOMERIC / NON-ELASTOMERIC
TEMPERATAURE RATING: 325 DEG F
CONNECTION: EUE OR GAS TIGHT CONNECTION
MATERIAL: CARBON STEEL OR CHROME METTALURGY
SHIFTING TOOLS: B TYPE / D TYPE
NEI-BN
NEI-BN, BN Shifting Tool is designed to selectively locate and shift most sliding sleeves. This is
accomplished by the Shifting Tool keys engaging the sliding sleeve insert and depending
on the direction the tool is run, up or down, the sleeve is shifted. The B shifting tool is
used to locate and either open or close a sliding sleeve
NEI-WWEG
NEI-WWEG, Wireline Entry Guide
TYPE: HALF MULE/FULL MULE
SIZES: 2 3/8, 2 7/8, 3 1/2, 4 1/2
CONNECTION: EUE OR GAS TIGHT CONNECTION
MATERIAL: CARBON STEEL OR CHROME METTALURGY
NEI-POPHS
NEI-POPHS, Pump Out Plug
TYPE: HALF MULE/FULL MULE
SIZES: 2 3/8, 2 7/8, 3 1/2, 4 1/2
CONNECTION: EUE OR GAS TIGHT CONNECTION
MATERIAL: CARBON STEEL OR CHROME METTALURGY
NEI-PPJS
NEI-PPJS, Perforated Pup Joint
SIZES: 2 3/8, 2 7/8, 3 1/2, 4 1/2
CONNECTION: EUE OR GAS TIGHT CONNECTION
MATERIAL: CARBON STEEL OR CHROME METTALURGY
NEI – LOCKMANDREL/PLUGS/EQUALIZING ASSEMBLY
PROFILE: OTIS (X, XN, R, RN)/BAKER TYPE (F/R)
PRESSURE RATING: 10,000 PSI
SEALS: PTFE
TEMPERATAURE RATING: 325 DEG F
MATERIAL: CARBON STEEL OR CHROME METTALURGY
RUNNING TOOLS: X OR R LINE RUNNING TOOLS
PULLING TOOLS: GS
NEI-XTI
NEI-XTI Running Tool is used to deploy the flow of subsurface control devices. It is used to run X
and XN lock mandrels in respective Landing Nipples. The fishing neck is connected to the
device to improve the industry standard connections
NEI-RTI Running
NEI-RTI Running Tool is used to run. The fishing neck is connected to the device to improve the
industry standard connections.
R Running Tool is used to deploy flow control devices e.g. R and RN lock mandrels by locating and
set in respective selective or bottom No-Go type Lock mandrels.
NEI-GSN
NEI-GSN, The GSN Pulling Tool is a basic wireline device which connects a wireline tool string
to a wireline retrievable flow control device that is to be run into or retrieved from
a well.
NEI-SBN
NEI-SBN, SBN Pulling Tool is designed to engage external fishing necks on subsurface devices within the
wellbore. The pulling tools are available with different core lengths, sized to accommodate the different reach lengths on industry standard fishing necks
